High Air Pressure DHD350 5'' Inch Down The Hole DTH Hammer and Bit for Hard Rock Drilling
The life of the DTH bit depends on the material and technology of the bit. The KSQ bit is made of the most efficient high quality alloy steel.
Use quality forged steel, heat treatment and shot peening to provide a durable and reliable balance of strength and toughness.
1. Long life of bit: alloy steel material has a long service life, which is higher than similar products;
2. High drilling efficiency: the drill teeth are wear-resistant, so that the drill bit can always be sharp, thus greatly improving the entering speed of the teeth;
3. Steady drilling speed: the drill bit breaks the rock by scraping and cutting;
4. Good spacing effect: the new diamond head has strong abrasion resistance and good spacing performance, which enables the cutting teeth to be utilized efficiently;
5. Wide application range: it has been proved by practice that this drill bit is suitable for drilling in soft and medium hard formations, such as carbonate rock, limestone, cretaceous rock, clay rock, siltstone and sandstone (below grade 9 of drillability,). Compared with general drills, especially in rock formations of grade 6-8, the effect is especially remarkable.
The submersible drill bit made by KSQ ranges from 2 inches to 40 inches in diameter and has a variety of the most common end face shapes, alloy tooth styles and shank styles to match the application and rock formations you are drilling in.
We can customize the drill bit according to your requirement. Different drill head shapes are selected according to different rock formations.
| For 5" hammer | Bit Dia. | No. | Gauge | Front | Weight | Part No. |
| DTH bits shank | mm | inch | Air Holes | Buttons | Buttons | (Kg) |
| DHD350R/COP54 | 133 | 5 1/4" | 2 | 7×φ16 | 6×φ14 | 15 | DHD350-133 |
| 140 | 5 1/2" | 2 | 7×φ18 | 7×φ14 | 16 | DHD350-140 |
| 146 | 5 3/4" | 2 | 8×φ18 | 7×φ14 | 17 | DHD350-146 |
| 152 | 6" | 2 | 8×φ18 | 8×φ14 | 17.5 | DHD350-152 |
| 165 | 6 1/2" | 2 | 8×φ18 | 8×φ16 | 18.5 | DHD350-165 |
Product information:
1. High and low air pressure down-the-hole drill bits
2. Low air pressure holeDia.:65-220mm
3. High air pressure hole Dia.:85-305mm
4. Face type: drop center bit/concave face/convex face/double gauge face/flat face bit
5. Carbide button shape: domed/round button parabolic/semi-ballistic button ballistic button sharp button flat button
6. Drill rock type: Granite, Marble, Limestone, Basalt, ect.
7. Project types: Blast holes, Quarry , Anchoring, Infrastructure, Geothermal holes, Well drilling,ect.
